New waveform generators

March 2, 2020

Six new arbitrary waveform generators (AWGs) have joined the M2p.65xx Series PCIe cards. The new AWGs boost the available output range to generate waveforms with amplitude swings up to ±12 V into 1 MΩ or ±6 V into 50 Ω. To achieve the higher output voltage ranges, the cards have been fitted with additional amplification and larger cooling plates. This makes the cards wider, so that they occupy two PCIe slots, but they are still just 168 mm in length and can fit into almost any PC, turning it into a flexible waveform generator.

Spectrum Instrumentation
