Open-Architecture ATE

The latest system-on-a-chip (SOC) and system-in-a-package (SIP) devices combine microelectromechanical systems, optoelectronic components, sensors, and traditional circuits in a single package. Generally, ATE vendors have not provided the instrumentation required to test all these elements in the time frame needed.

One cost-effective solution is an open-architecture ATE (OA-ATE) system that allows specialized semiconductor manufacturers to specify the instrumentation they require. OA-ATE must incorporate these vital elements:

  • An industry-standard bus structure.
  • Compatibility with industry-standard data formats.
  • Browser technology to access and control resources.
  • A modular hardware and software structure to enable reconfigurability.
  • Partitioned test supported by ATE and EDA tools.

Incorporating these elements puts in place a number of characteristics that influence and substantially improve time-to-market and cost-of-test. Table 1 lists some of the more important advantages.

Conventional ATE OA-ATE Impact
Instrumentation Limited variety
High cost
Large number available (>1,000)
Shared development cost
Flexibility; up
Cost: down
Software Tester specific
Proprietary
Monolithic
Hardware-independent
Industry standard
Modular
Improved IP reuse
Trained engineers available
Cost: down
Time-to-market: down
Resource libraries Not available Test libraries
Tool libraries
Probe pad and package libraries
Consistency improved
Time-to-market: down
Cost: down
Expertise required: down
Configurability Limited by available instruments
Complex process for hardware and software
Universal pin card slot
Modular hardware and software
Industry standard bus
Plug-and-play instruments
Flexibility improved
Cost: down
Time-to-market: down
Depreciation life: up
Calibration External instrumentation required
Full recalibration required after reconfiguration
NIST-traceable internal calibration on most instruments
Calibration required only for added resources
More reliable calibration
Hours saved with each reconfiguration

Table 1. Conventional vs. OA-ATE

Costs

The 2000 International Technology Roadmap for Semiconductors (ITRS) forecasted ATE costs in excess of $20 million. This was reduced in 2001 to approximately $6 million as the financial impact of design-for-test (DFT) technology was recognized. This is a marked improvement but still inappropriate for devices with an average selling price under $2.

The ITRS identifies several approaches that alter test strategy cost in an effort to arrest test-cost escalation. For example, the constantly increasing frequency, accuracy, and I/O count in integrated circuits (ICs) are being addressed by DFT solutions that may be successful for high-volume digital devices but do not solve the industry cost problem.

Many ATE systems still list above $1.5 million, and test times are escalating as device size and complexity increase. These ATE systems are not unreasonably priced since their architectures incorporate expensive, custom-engineered subsystems. They remain large and power hungry because of the special-purpose bus structures used to deliver the bandwidth and high thermal density used to provide the required accuracy. In addition, the traditional ATE architectures fail to take advantage of lower-cost industry-standard instruments.

Industry-Standard Instrumentation

The instrumentation industry supports a number of standards for bus structures and form factors, including PCI and PXI. By using instruments conforming to these standards wherever they can be implemented, ATE manufacturers can reduce development time and system costs.

Other economic advantages are associated with conformance to industry standards. Development and maintenance of software, availability of advanced programming tools, and ease of intellectual property reuse all can be improved. Over time, these factors may be even more important than ATE cost-of-ownership but are not quantified here.

Product life cycles have decreased significantly, driven by consumer demand and enabled by advances in design tools and acceleration of fabrication technology. These reduced cycles require shorter time-to-market, and production test constraints often are the gating issue.

EDA tools providing automatic test pattern generation (ATPG) have made progress in memory and logic testing, but most SOC ICs today incorporate analog elements and specialized circuits not supported by existing ATPG technology. Custom load-board solutions often are required for complex mixed-signal parts, making the task more difficult and time-consuming.

In general, the ATE industry has been slow to adopt the promising technologies that enable reductions in time-to-market required by the IC manufacturers. EDA tools already incorporate co-design of circuits, packages, and test strategies. Both ATE and EDA tools also must enable test partitioning between various DFT approaches and traditional ATE.

These features must be supported to meet the imperatives of shorter time-to-market and lower cost-of-test. The closed architectures and one-dimensional EDA tools that dominate the landscape today will not be viable in the new generation of ICs.

User Reconfigurability

Complex circuits must use DFT techniques to control test cost. The initial validation of any new design uses conventional ATE for device characterization and verification of DFT techniques. This ATE is expensive and inconsistent with cost-effective production.

Also, conversion to a lower-cost ATE system for production following characterization is costly and time-consuming. A better solution is a configurable system that can be quickly altered to meet either device characterization or production test.

The architectures for conventional ATE and reconfigurable ATE are shown in Figure 1 and Figure 2, respectively. Reconfigurability allows rapid change of instrumentation, disturbing only the signal paths that require resource changes. This makes it practical to use device-specific tester configurations that always deliver the lowest cost because no unused resources are in the system.

The Internet and virtual private networks (VPNs) make it possible for a virtual semiconductor company without fabrication facilities or test and assembly operations to have timely access to information previously enjoyed only by independent device manufacturers. Internet-compatible, browser-enabled ATE makes data available anywhere in real time with only Internet latency. This supports more rapid problem identification and resolution (Table 2).

Conventional ATE Internet-Enabled ATE Impact
Distributed Test Only accomplished through expensive third-party tools Fully supported through available tools using a VPN Better data availability
Flexibility in resource management
Lower cost
Yield Enhancement Expensive third party All data from all systems available in real time Rapid identification of yield loss or other inefficiencies
Diagnostics/Repair Local to the system Can be run locally or over a VPN Improved availability
Remote repair
Configurability Requires ATE specialist with device knowledge On-line configuration can determine instruments needed Reduced engineering expertise required
Flexibility improved

Table 2. Internet-Compatible Browser-Enabled vs. Conventional ATE

Case Studies

The following case studies are based on actual results by ATE users rather than system specifications. In some cases, the ATE specifications defined for ideal conditions were not achieved in actual testing.

Data Converter

A 14-bit, high-speed analog-to-digital converter (ADC) is typical of the emerging ATE challenges. The test requirements were not met by conventional ATE that was evaluated because it lacked the desired measurement resolution, could not demonstrate the required noise floor, or both. Table 3 provides a comparison of conventional and OA-ATE in this application.

Parameter Conventional ATE OA-ATE Force Resolution 16-bit Differential ±2 V 16-bit Differential ±2 V Measure Resolution 18 bit
Proprietary instrument
24 bit
Industry-standard instrument
Footprint and Weight>50 ft2; >1,000 lb Customer-Specific Instrumentation Not available: would require expensive loadboard solution Not available: developed and integrated in < 6 weeks System Cost $900,000 $180,000 System Noise Floor -90 dBm -120 dBm

Table 3. 14-Bit, High-Speed Data Converter
Probe Test for Characterization and Device Debug—243 Pins
High-Precision Differential Stimulus
High-Precision Calibration
Trim Algorithm Included in the Test Program
Numerous Control and Measure Points

Cost, size, and power advantages for OA-ATE are perhaps the most obvious but not the most important. Specialized instrumentation required in the characterization phase was easily developed and integrated into the OA-ATE, taking advantage of hardware and software infrastructures to reduce cost and time-to-market. Providing these resources via load boards costs more and takes longer.

SIP Devices

The emergence of SIP configurations poses similar challenges. In this case, the four-chip SIP required 50 A and 900 V. These are not available with conventional ATE pin cards, so a costly load-board solution was implemented, which delayed test-program development and increased total cost. The conventional ATE solution was functionally adequate but hampered by high cost and long execution time. Introducing OA-ATE to the problem enabled delivery of all test resources from pin cards.

The size, power, and cost of the system were reduced significantly, but the dominant advantage was improved test time. The characteristics contrasting the two solutions are listed in Table 4. These examples indicate that conventional ATE gets the test job done but at a slower pace and a higher cost than with OA-ATE.

Parameter Conventional ATE OA-ATE
Load Board Complexity Special circuits for high-voltage and high-current stimulus No special circuitry
Test Time 43 s 15 s
Footprint and Weight >20 ft2; >1,000 lb < 6 ft2; < 100 lb
Power Requirements > 2 kW 600 W
System Cost $550,000 $165,000
External Instrumentation High-voltage supply
High-current supply
None; high-voltage/high-current plug-in cards currently available
Table 4. Four-Chip SIP
Final Package Test—43 Nodes
Circuit Elements Tested Include MOSFETs, IGBTs
High Current: 80-A Peak
High Voltage: 900-V Peak
Leakage Current: <10 nA

The application of OA-ATE delivers the following benefits in advanced SOC and SIP testing:

  • A drop in per-transistor test costs.
  • An order of magnitude reduction in test-related time-to-market delays.
  • Efficient partitioning of test through device and test co-design.
  • Insertion of home-grown hardware and software components supported by open-architecture industry standards.

About the Author

W. R. (Bill) Bottoms is founder and chairman of the board of 3MTS. Dr. Bottoms was appointed to the faculty of Princeton University in 1969 and since then has served as the initial president of the Semiconductor Equipment Group of Varian Associates and chairman and CEO of Credence. Prior to joining Credence, Dr. Bottoms spent more than 10 years in the venture capital industry as a partner of APA. Third Millennium Test Solutions, 2160 Lundy Ave., Suite 110, San Jose, CA 95131, 408-435-1788, e-mail: [email protected]

Return to EE Home Page

Published by EE-Evaluation Engineering
All contents © 2002 Nelson Publishing Inc.
No reprint, distribution, or reuse in any medium is permitted
without the express written consent of the publisher.

October 2002
