Immunity Test System

The ITS 6006 performs radiated EMC emissions testing over an 80-MHz to 6-GHz frequency range. The system comprises an RF signal generator with AM and PM modulators, RF switches, inputs for up to three external power meters, EUT monitoring and control ports, amplifier control outputs, and software for EMC testing. Multiple EUTs can be monitored and controlled via four TTL outputs and eight inputs. An integrated switch network allows the RF signal generator to be switched to one of up to four directly connected power amplifiers. Two additional RF switches can be used to combine two amplifier output paths into a single antenna connection.
