Changing Embedded Motherboard Expansion Options

June 28, 2017
How are embedded motherboards changing? We check out new features like multiple Mini-PCI Express sockets and M.2 flash memory to see what options designers now have available.

Download this article as a .PDF

Embedded motherboard designs change slowly when it comes to peripheral interfaces. ISA-based interfaces like PC/104-Plus remain because it supports legacy boards and it is easy to design peripheral boards, but the interface for the future is PCI Express (PCIe). While there are a host of PCIe daughter board options, the Mini-PCIe form factor offers a compact expansion option for embedded motherboards.

A single Mini-PCIe socket has been commonly found on embedded motherboards for some time, but the number of sockets is increasing as developers are finding more ways to embed peripherals via Mini-PCIe modules. These can often replace the peripherals on legacy boards that take up significantly more space and use more power. The x1 PCIe interface provides sufficient bandwidth for high-speed peripherals, and the multifunction socket can often support interface like SATA in the form of mSATA modules.

Diamond Systems’ Venus (Fig. 1) motherboard supports Intel’s “Skylake” 6th generation Core i7/i5 U series processor. It includes a pair of Mini-PCIe sockets, one of which supports mSATA modules. The single-board computer (SBC) also has PCI-104 and OneBank socket for stackable expansion boards. The OnBank has four x1 PCI Express ports and two USB ports. As with a typical SBC, the Venus includes networking support with a pair of Gigabit Ethernet ports, additional SATA ports, multiple video graphic outputs, and audio support. It has 16 digital ports but lacks analog support that can be easily added using the expansion sockets

VersaLogic’s Viper (Fig. 2) is an EBX SBC that hosts Intel’s Bay Trail Atom processors. It has similar expansion and peripherals as the Venus, although it has PC/104-Plus that includes ISA and PCI sockets. There is a pair of Mini-PCIe sockets with mSATA support. The SBC also has two Gigabit Ethernet ports, plus USB 3.0 support, as well as an 8-channel, 12-bit ADC and 4-channel, 12-bit DAC. The two Mini-PCIe sockets can augment these interfaces or add functionality, such as GPS or wireless networking support.

The WinSystems EPX-C414 (Fig. 3) is similar to the Viper with a Bay Trail processor and two Mini-PCIe sockets. It has 48 digital I/O ports, dual-gigabit Ethernet, and USB 2.0 ports and four serial ports. There is a CFast socket, as well as mSATA support on the Mini-PCIe sockets.

The other expansion port that is becoming more common is the M.2 socket; typically used for storage, it also can support peripherals. It can have up to a x4 PCI Express interface that supports NVMe or a SATA interface (see “What's The Difference Between SATA And NVMe?”). NVMe has the speed advantage, and M.2 modules are available in higher capacities than Mini-PCIe modules, because the M.2 modules can be larger.

Super Microcomputer (SuperMicro) has a number of embedded motherboards that have an M.2 socket as well as a Mini-PCIe socket. The X10SDV-12C-TLN4F (Fig. 4) can run a 12-core Intel Xeon, and it sports a Mini-PCIe and x4 PCIe M.2 socket, along with two 10 Gbit Ethernet ports and two 1 Gbit Ethernet ports.

M.2 has higher capacity storage solutions compared to Mini-PCIe, but there are currently no M.2 modules that match the more rugged specifications of many Mini-PCIe modules. Developers that require high capacities may have to resort to SATA drives that will take up more space.

Motherboards with even more Mini-PCIe and M.2 sockets are becoming available. This allows developers to take advantage of the larger number of PCIe ports available on new systems. This can allow designers to create more compact and flexible systems without the need for daughterboard expansion.
