Frequency Quadrupler Enables Low-Frequency Measurements, Spans Up To Four Decades

March 6, 2014
The challenge in measuring low frequencies is that the counter gate time is often too short for the signal relatively long period. This non-critical circuit automatically multiplies an input single frequency times four to enable measurement of frequencies from 1 Hz to 40 kHz, tracking step changes in the input frequency as well.

This article is part of the Ideas for Design Series: Vol. 3, No. 2

In frequency counters, the gating time allotted for counting is often too short to resolve low frequencies. A phase-locked loop could be used to multiply the input frequency. But in some cases, the signal changes too fast or too far for lock to be acquired or maintained.

Related Articles

To solve the problem, the circuit of Figure 1 is used to multiply the input frequency by a factor of four, spanning a range of 1 Hz to over 40 kHz, and it will track a step change anywhere in that range.

There is one issue with this simple implementation, though. The constant delay at U2D (as seen at U3B output) tends to cause counting-by-twos in the lower decades (Fig. 2)
A circuit that eliminates this issue provides a quadrature output over the frequency range (Fig. 3). Phase-lead and phase-lag circuits are used to create a constant 180° phase difference with respect to input frequency, at op-amp outputs (U5A and U5B).
Connecting the comparator inputs U6A and U6B to the op amps U5A and U5B reduces the phase difference to 90°, as measured from one comparator output to the other. Constant phase means variable delay, overcoming the issue with the circuit.

Figure 4 shows the benefits provided by the quadrature circuit. The first XOR gate, U8A, produces the exclusive OR of the two quadrature outputs, U7A and U7C. This multiplies the input frequency by two. The second XOR gate, U8D, produces a pulse for each positive and negative edge of the signal from U8A, again multiplying by two. The result is four equally spaced output pulses at U8D for each cycle at the input.

Quadrature maintains equal output pulse spacing as the frequency changes, so gating the pulse train will always count by ones. Quadrature is maintained within +0/–5° from 1 Hz to 49 kHz, but is lost above 49 kHz with the circuit values shown.

Accurate tracking speed may be limited by the time required to acquire four output pulses at the new frequency from a step change to an accurate count, effectively a delay of 1/f seconds. This implies that accurate tracking is a function of the input frequency. Stepping from a higher to a lower frequency would require at least 1/flower seconds for the output to settle at four times the input frequency.

The output pulse is set wide enough to be reliably captured by the processor or other counter input. If it is too wide, it will limit the upper frequency at which multiplication can be achieved. Too narrow, and the microprocessor or counter will miss counts.

With the components shown, the output is a 5.6-μs pulse. This restricts the maximum theoretical multiplied output frequency to 89.3 kHz (input frequency less than or equal to 22.3 kHz). The quadrature circuit component values limit the maximum input frequency to 49 kHz or 196 kHz at the output of the multiplier. If the output pulse width could be made as short as 2.5 μs, the maximum multiplied output frequency would reach 196 kHz.

Adjusting component values can move the usable range of multiplication higher or lower than that described here to fit the user’s requirements. With faster op amps, comparators, and logic components, the design might be able to perform at RF frequencies.

Read more articles from the Ideas for Design Series: Vol. 3, No. 2

Download this article in .PDF format
This file type includes high resolution graphics and schematics when applicable.

Dave Conrad is a retired analog/digital hardware engineer who learned electronics by reading (starting at age 6) publications such as the ARRL Radio Handbook, QST, and CQ and later from various library books and Popular Electronics magazine. This was followed by a few courses in electronics in high school and junior colleges including TTL logic, along with learning on the job.
