Use Advanced PCB Technology To Produce 50% Smaller Product Designs

April 21, 2014
High-density interconnect (HDI) technology allows PCB designers to increase the routing density, reduce the layer count, and improve the thermal and electrical characteristics of their board designs. Advanced via technology allows two conventional eight-layer cards to be combined into one 18-layer HDI card creating a product that is 50% smaller.

This article is part of the Ideas for Design Series: Vol. 3, No. 5

High-density interconnect (HDI) technology allows printed-circuit board (PCB) designers to increase routing density, reduce layer count, and improve the thermal and electrical characteristics of their board designs. This approach uses advanced via technology to combine two conventional eight-layer cards into a single 18-layer HDI card. The cards can use their own power supplies or share a redesigned one, creating a product that is 50% smaller.

Download this article in .PDF format
This file type includes high resolution graphics and schematics when applicable.

Related Articles

PCB vias come in different configurations (Fig. 1). Through-hole (TH) vias originate and terminate at the outer layers of the PCB, while blind vias originate on an outer layer and terminate on an inner layer. Buried vias are completely buried within the board, connecting only inner layers and not reaching the outer layers at all. Microvias are a form of blind vias that penetrate only one or two layers, and they have an extremely small drill hole (from 0.008 in./0.2 mm all the way down to 0.004 in./0.102 mm).

1. Vias come in different configurations including through-hole, blind, micro, and hidden.

In addition to using microvias, blind vias, and buried vias, this technique requires careful electromagnetic interference (EMI) and thermal analysis, PCB layer stackup, and power/signal/ground distributions. When combined, the two cards look like Figure 2. To combine the boards, you’ll need to:

• Ensure that the on-board power supplies can be split evenly between the two eight-layer sections, or newly designed power supplies for two cards are in place

• Change all through-hole parts to surface-mount (SMT) parts, and change the placement to single-sided

• Mirror and combine the card layouts, so layer 1 to layer 8 is the first card and layer 11 to layer 18 is the second.

• Use blind vias or buried vias for the power and ground nets that connect to or cross layers 9 and 10

2. Multilayer boards can incorporate different types of vias to minimize the number of layers required.

You’ll also need to be sure that when you place the ball-grid array (BGA) components that require decoupling capacitors that there is space for the capacitors on the mirrored locations underneath those BGA packages.

In addition, if a completely new layout design for the conventional card is permitted (beyond the changes described above), the two cards can be designed back-to-back directly. In that case, the bottom sides of the two cards would be layer 9 and layer 10 after the combination. This would yield a single 16-layer HDI board over two eight-layer conventional boards.

This approach is just one case where HDI PCB technology allows us to create designs that weren’t possible until recently. There are other examples as well.

Pi Zhang is a senior design engineer at Nuvation Engineering, a design firm specializing in new product development and electronic design services.

Read more articles in the Ideas for Design Series: Vol. 3

About the Author

Pi Zhang | Senior Design Engineer

Pi Zhang is a senior design engineer at Nuvation Engineering, a design firm specializing in new product development and electronic design services.
