High-Voltage AC/DC Module Produces Up To 12 kV

The newest line of single output high-voltage AC/DC modules of UltraVolt, Inc.,  the B Series,  comprises 2 models that provide fixed outputs of 1 kV to 12 kV at 4, 20, 30, or 50 watts of output power. B Series units are available with an input voltage of either 115 VAC or 230 VAC. The B Series is less expensive than a two-module AC to DC and DC to DC module solution, making the series ideal for lower cost capital-equipment applications. Features on the new line include indefinite output short-circuit protection and output arc protection. Other features include a fault monitor with isolated relay contacts and a fixed-frequency, low-stored-energy design. These modules are UL, cUL, IEC-60950-1, and Demko Recognized.

The B Series of high-voltage regulated AC-DC converters addresses the need for an AC line operated, fully integrated, chassis-mount fixed-output regulated high-voltage power supply with nominal performance and limited functions. These modules are designed and built utilizing state-of-the-art power-conversion topology. B Series units feature design, manufacturing process, and encapsulation techniques that provide high reliability.

Typical B Series applications include bias supplies, isolation testers, electrostatics, air ionization, air & oil precipitators, ozone generators, UV lamps, capacitor charging, and flash lamps.
