110 V LED Controller Has Spread Spectrum Frequency Modulation
The LT3795 from Linear Technology is a 110 V, high-side current sense DC/DC converter designed to regulate a current or voltage to a constant value, ideal for driving high brightness (HB) LEDs. Its 4.5 V to 110 V input voltage range makes it appropriate for a wide variety of applications, including automotive, industrial and architectural lighting. The LT3795 uses an external low side N-channel MOSFET and can drive up to 90 V of white LEDs from a nominal 12 V input, delivering in excess of 50 watts. Spread spectrum frequency modulation reduces EMI emissions, while an internal PMOS switch driver delivers robust short-circuit protection in boost and buck-boost topologies. The LT3795 incorporates a high-side current sense, enabling it to be used in boost, buck, buck-boost or SEPIC topologies. Additionally it offers current both input and output current limiting and monitoring for added reliability and design flexibility. The LT3795 can deliver efficiencies of over 94% in boost mode, minimizing the need for external heat sinking. A frequency adjust pin permits the user to program the frequency between 100kHz and 1MHz, optimizing efficiency while minimizing external component size and cost. Combined with a thermally enhanced TSSOP-28 package, the LT3795 offers a very compact HB LED driver or charger solution.
The LT3795 uses PWM dimming, which delivers constant LED color with dimming ranges of up to 3,000:1. For less demanding dimming requirements, the CTRL pin can be used to offer a 10:1 analog dimming range. Its fixed frequency, current mode architecture offers stable operation over a wide range of supply and output voltages. Robust open and short-circuit protection maximize overall system reliability, while C/10 detection optimizes both battery and SuperCap charging designs. Additional features include input and output current reporting, frequency synchronization, programmable UVLO and a programmable fault restart timer.
The LT3795EFE is available in a thermally enhanced TSSOP-28 package. Pricing starts at $3.45 each. An extended temperature version or I grade, the LT3795IFE, is also available with pricing starting at $3.86 each. Finally, a high temperature, or H grade, the LT3795HFE is available, the pricing starts at $4.11 each. All prices are in 1,000-piece quantities and all versions are available from stock.
