Quad-MOSFET Solution Boosts Efficiency

July 10, 2013

Fairchild Semiconductor's FDMQ86530L 60V quad-MOSFET provides designers with an all-in-one package to help with critical design challenges of heating and efficiency.

Fairchild Semiconductor's FDMQ86530L 60V quad-MOSFET provides designers with an all-in-one package to help with critical design challenges of heating and efficiency. Comprised of four 60V N-Channel MOSFETs and utilizing Fairchild's GreenBridge™ technology, the FDMQ86530L solution improves the conduction loss and efficiency of the conventional diode bridge providing a ten-fold improvement in power dissipation. Available in a thermally enhanced, space-saving 4.5 x 5.0 mm MLP 12-lead package, the device eliminates the need for a heat sink enabling a compact design that increases power conversion efficiency in 12 and 24V AC applications.

Specifications:

Max R_DS(ON) = 17.5 mΩ at V_GS = 10V, ID = 8A
Max R_DS(ON) = 23 mΩ at V_GS = 6V, ID = 7A
Max R_DS(ON) = 25 mΩ at V_GS = 4.5V, ID = 6.5A

Samples available upon request - Delivery 8-12 weeks ARO The FDMQ86530L product is available in a 4.5 x 5.0mm MLP 12-lead package and is priced at $1.38 in 1,000 quantities.
