20 V MOSFET in PowerPAK® SC-70 Brings Power Density, Reliability

Vishay Intertechnology, Inc. released a  20 V n-channel TrenchFET® power MOSFET in the ultra-compact thermally enhanced PowerPAK® SC-70 package. Providing increased power density and reliability for portable electronics, the Vishay Siliconix SiA466EDJ offers the industry's highest package-limited continuous drain current for a 20 V MOSFET in the 2 mm by 2 mm footprint area, and it is the only such device with a VGS rating of ±20 V to provide integrated ESD protection.

The SiA466EDJ's 25 A package-limited continuous drain current is 13 % higher than the closest competing device. In load switch applications, the high current rating provides an additional safety margin for large in-rush currents and fault conditions including short circuits. The MOSFET's 2500 V integrated ESD protection prevents static damage from handling or human body contact.

The device released today is a versatile solution for power management in portable equipment designs. The combination of a high current rating and excellent on-resistance times gate charge figure of merit (FOM) optimizes synchronous buck converters and load switches in wireless and fast battery chargers, smartphones, tablets, notebook computers, and e-locks.

To increase efficiency in high-frequency switching applications, the SiA466EDJ's low on-resistance of 9.5 mW (10 V), 11.1 mW (6 V), and 13.0 mW (4.5 V) reduces conduction losses, while its low 6.3 nC typical gate charge and 0.9 W gate resistance minimize switching losses. The MOSFET is 100 % RG-tested, RoHS-compliant, and halogen-free.

Samples and production quantities of the SiA466EDJ are available now, with lead times of 13 weeks for large orders. Pricing for U.S. delivery only starts at $0.32 per piece.
