    650V IGBT Portfolio Optimized for Motor Drive Applications

    Aug. 31, 2015
    Alpha and Omega Semiconductor Limited (AOS) recently announced the expansion of its IGBT product portfolio with the release of the 650V M-Series.

    Alpha and Omega Semiconductor Ltd. (AOS) recently announced the expansion of its IGBT product portfolio with the release of the 650V M-Series. The new M-series is co-packaged with a soft and fast freewheeling diode available in a variety of package types. This platform has been optimized for high performance in addition to fast and soft turn-off switching in motor drives such as refrigerators, washing machines, fans, air conditioners, treadmills, and sewing machines applications.

    All devices for the M-Series are built upon the patent-pending AlphaIGBT™ technology platform, and feature low VCE(SAT) and soft turn-off for higher efficiency and reduced power dissipation. The 650V-minimum BVCES rating and rugged breakdown voltage characteristics provide higher reliability during extreme voltage transients. Furthermore, low turn-on di/dt and high turn-on dv/dt switching performance effectively reduces EMI.

    650V M-Series Technical Highlights

    • 650V IGBTs with soft and fast freewheeling diode
    • High turn-on performance by low di/dt and high dv/dt
    • Fast and soft turn-off switching performance
    • Short circuit rating (tsc) of > 5µs at 400VCC, 15VGE and 150°C
    • TJ(max) = 175°C

    The 650V M-Series IGBTs are immediately available in production quantities with a lead-time of 12 to 14 weeks. Contact AOS representatives for samples and pricing.
