Low EMI Diode for LED Backlighting of TVs, Monitors and LED Ballast Lighting

March 29, 2016
Qspeed diodes are amongst the fastest diodes in the world and have extremely low Qrr, which is important in high-efficiency applications.

Qspeed diodes are amongst the fastest diodes in the world and have extremely low Qrr, which is important in high-efficiency applications. Devices feature a reduced reverse recovery current which lowers the switching losses in the MOSFET of the flyback converter dropping its temperature by 6°C and improving efficiency by 0.3%. Compared to other high voltage diodes, the soft switching of the Qspeed diode reduces its peak reverse voltage by over 5%, resulting in a higher derating margin and increased operational reliability.

The lower peak voltage of the 530V Qspeed diode and its softer switching behavior mean that minimal EMC snubbing is required, and SO-8 packaging further suits height and volume constrained applications.
