Intersil Corporation announced the ISL2802x family of digital power monitors capable of supporting a wide common mode input voltage range of 0V to 60V. The ISL2802x family is comprised of three devices offering a range of capability including full featured bi-directional, high-side and low-side digital current sense and voltage monitors with a serial interface with a high level of integration. Precision measurements are enabled by an integrated 16-bit ADC. Available in a tiny solution footprint and with a wide specified temperature range, the ISL2802x digital power monitor family is ideal for telecom, industrial and consumer applications.
Current, voltage and power measurements are fundamental to monitoring electronics and are critically important to measuring the health of a power system. Basic op amps and current sense amplifiers can be used for this purpose, but require complicated analog design while providing limited real-time system information. Through key architectural innovations, Intersil's ISL2802x digital power monitors integrate many common electronic building blocks resulting in system designs that have reduced complexity without compromising performance.
The ISL2802x family consists of the three unique products. The ISL28023 is a full featured PMBus compatible digital power monitor that integrates the analog comparators, a voltage regulator, a DAC and a low voltage auxiliary channel in a single chip. The ISL28025 is a high precision digital power monitor with integrated analog comparators and an integrated voltage regulator. The integrated analog comparators for the ISL28023/5 allow for continuous monitoring of the inputs. This results in a very fast response time (500nS) enabling real-time alerts for rapid system shut off if necessary. The ISL28022 is a highly efficient digital power monitor ideal for cost constrained applications.
The ISL2802x family delivers high accuracy measurements through an integrated 16-bit native resolution sigma-delta ADC (gain error = ±0.05% Typ.) in a wide input common mode voltage range (0Vto 60V) providing designers with a high level of safety margin that is often necessary in wired, wireless and data infrastructure applications. In addition, the wide specified temperature range from -40ºC to 125ºC provides greater design flexibility.
The ISL2802x family is available now. Pricing for the ISL2802x devices starts at $0.95 USD in 1k quantities. The ISL28023 full-featured digital power monitor is offered in a 24 lead 4x4mm QFN package.
The ISL2802x family is supported by the ISL28022EVKIT1Z, ISL28023EVKIT1Z and ISL28025EVKIT1Z evaluation kits available for $70 USD each.
