Generation EZBuck(TM) Regulator Comes In Thermally Enhanced Package

Feb. 17, 2015
Alpha and Omega Semiconductor Limited (AOS) announced the release of the fifth generation EZBuck(TM) with the AOZ3103, a high efficiency, simple-to-use synchronous buck regulator

Alpha and Omega Semiconductor Limited (AOS) announced the release of the fifth generation EZBuck(TM) with the AOZ3103, a high efficiency, simple-to-use synchronous buck regulator, with an operating input voltage range from 4.5 V to 18 V and the ability to supply 3A of continuous current. The device offers a low on-resistance power stage in a thermally enhanced 3mm x 3mm DFN package, allowing cooler power conversion for a variety of consumer electronics applications such as LCD TVs, set-top-boxes, as well as DVD players and recorders.

The AOZ3103 is a current-mode step-down regulator with integrated high-side and low-side NMOS switches. The device features external compensation for added design flexibility, and to improve performance in low duty cycle applications. Compared to the leading competitor, the AOZ3103's input voltage rating is 2 V higher and its feedback tolerance is 0.5% tighter, which allows for greater safety design margin as well as a higher degree of output voltage accuracy. The device also features a Power-On Reset (POR), input under-voltage lockout and output over-voltage protection.

Technical Highlights:

  Input Range:                  4.5 V to 18 V

  FET On-resistance (typ):  High-side (80 mW). Low-side (30mW)

  Switching Frequency:      500 KHz

  Package:                       DFN3x3-8L

  Compensation:                External

  Feedback Tolerance:      ± 1.5%

The AOZ3103 is immediately available in production quantities with a lead-time of 12 weeks. The unit price of 1,000 pieces is $1.03.
