Ultralow Power Buck Regulator Achieves Industry's High Power Conversion Efficiency

Analog Devices Inc. recently introduced an ultralow power buck regulator that extends battery life in portable devices by achieving the industry's highest ultra-light-load power conversion efficiency.

With a 90 percent efficiency rating and consuming only 180-nA quiescent current, the ADP5301 buck regulator is designed to deliver maximum power for a longer period of time than previously achievable and is ideally suited for Internet of Things (IoT) applications, including wireless sensor networks and wearable devices such as fitness bands and smartwatches. The new device is housed in a tiny WLCSP package that measures less than 3.1-mm², which makes it suitable for small form factors.

Key Features:

• 90 percent power conversion efficiency in ultralight load with 180-nA quiescent current boosts battery life
• 6.5-V to 2.05-V input voltage range enables wide range of battery sources or architectures
• Selectable, low-noise forced PWM mode with low output voltage ripple powers noise-sensitive analog load up to 500-mA output current capability
• Integrated voltage supervisory function increases overall system reliability
