Teseq offers artificial networks for conducted emission testing

July 12, 2015

Edison, N.J. Teseq has introduced two high-voltage artificial networks designed for conducted emission tests and line termination during susceptibility tests for components. The HV-AN 150 and HV-AN S150 are suitable for use in automotive, military, and airborne standards applications.

These two new line impedance stabilization networks (LISNs) offer a unique approach to e-mobility as well as help meet the need for increasing voltage and current values inside of vehicles.

Teseq’s HV-AN 150 offers a universal solution with its jumper settings that covers the traditional way of testing as performed in CISPR 12, CISPR 25, and ISO 7637-2. The combination of two networks in a shielded box enables the testing of shielded high-voltage connections as seen in standard drafts of CISPR 12, CISPR 25, and ISO 7637-4.

Teseq’s HV-AN S150 allows users a direct connection with a special high-voltage connector that avoids any shielding problems. It offers a solution for high-current, high-voltage, and shielded connections to equipment under test (EUT). No additional shielding box is required when using this unit. It meets the draft versions of CISPR 12, CISPR 25, and ISO7637-4.

The HV-AN 150’s frequency range and power ratings are related to the selected standard per jumper setting.

www.teseq.com/product-categories/line-impedance-stabilization-networks-lisn.php
