IDEC released the microcontroller-based HR6S safety relay module, which supports a wide variety of connections, input devices, and operating modes, while adding convenient diagnostic and status monitoring important for the growing number of manufacturing sites relying on important Industrial IoT data. The adaptable HR6S safety relay module is designed to meet ISO 13849 requirements, with one model for low-risk Safety Category 1 applications, and six models suitable high-risk Safety Category 3 and 4 processes requiring redundancy.
Up to eight different start modes are dial-selectable, including options for manual and automatic start, providing extensive flexibility. Certain models have adjustable off-delays, and all use a compact DIN-mountable form factor. An expansion module is available to expand the number of safety outputs. Depending on the model, up to seven types of input devices are dial-selectable, including emergency stop switches, two-handed switches, pressure-sensitive devices, and other types of interlock switches. Terminations are arranged intuitively, with terminal blocks available as push-in or screw type to meet any user need, and both styles are removeable for easy serviceability.
Maintainability and convenience are aided by multiple LEDs with steady and/or flashing colored lights indicating various conditions such as power, error, operating state, and more. Users can quickly check the status on-site, identifying any issues so immediate action can be taken. HR6S safety relay modules can output 20 different indications of operational status, errors, and alerts. This enables supervisory control systems and IoT platforms to perform visualization, diagnostics, preventative maintenance, and other analytics. These signals are transmitted using a pulse signal to encode the information so it can be interpreted by a standard PLC input module using ladder logic.
The HR6S safety relay module family simplifies the task of Safety Category 1, 3, and 4 equipment safety design, and delivers extensive IoT data to keep production online and improve worker safety. Soon, the HR5S safety relay module will be released to meet Category 2 requirements.
