What's the Difference Between JSON, XML, and YAML?

April 28, 2015
These text-file formats can all be used to store structured data for embedded and Web applications—but there are differences among them.

What are JSON, XML, and YAML? Text-file formats that can be used to store structured data that can be handy for embedded and Web applications.

Most developers will be familiar with XML (Extensible Markup Language) and its flexible but powerful markup capabilities (see “XML: Flexibility Where It Counts”). It is often used in configuration and preference files like those used for the Eclipse IDE. Most Web browsers have XML viewers, although XML is designed for structured data, making it a bit like looking at the internals of a database.

JavaScript Object Notation (JSON) is used with JavaScript, of course. It will be familiar to Web developers that use it for client/server communication.

YAML stands for YAML Ain’t Markup Language. It uses line and whitespace delimiters instead of explicitly marked blocks that could span one or more lines like XML and JSON. This approach is used in many programming languages, such as Python.

Each has its advantages and supporters. This is not a definitive description of JSON, XML, and YAML, but rather a short overview that would allow someone to actually understand how they work and possibly read existing examples. All are applicable to embedded applications where data is stored and exchanged. Each one is very popular, although there are other alternatives as well. Functions to read and write these formats are available in just about every programming language, although general data conversion works best for programming languages that support keyed collections. We will defer the discussion of schemas to another article.


XML is defined by the World Wide Web Consortium's (W3C') XML 1.0 Specification. It was designed to be general, allowing it to be used in a wide range of applications. It is a balanced version of Hypertext Markup Language (HTML) and there is the Extensible Hypertext Markup Language (XHTML) definition. HTML was less strict leading to more compact files (Fig. 1).

This is a paragraph.

This is another paragraph.

1. Initially HTML allowed unbalanced prefixes.

Of course, this leads to some interesting problems. It turns out to be good practice to have “well-formed” definitions so, for example, paragraph definitions are bounded by


(Fig. 2).

This is a paragraph.

This is another paragraph.

2. Web browsers prefer HTML that is properly formatted like this.

HTML has specific syntax and semantics to address presentation issues like layout, fonts, and so on.

XML is stricter as is XHTML. XML requires well-formed data (Fig. 3)

Charles Schulz Walt Elias Disney Gary Larson

3. This XML data is a hierarchy of people and their names.

The indents in the example make XML easier to read, but the whitespace is irrelevant. This is highlighted by the name elements (firstName, middleName, and lastName) that appear on a single line or multiple lines. Note the matching “tags” with the trailing tag starting with a slash character, “/”.

Tags can also include attributes (Fig. 4). The example also shows an alternate form where the trailing tag is eliminated as designated by the trailing slash. This is used when there is no data although information is usually provide in the form of attributes.

4. Tags can include attributes like src and alt in this example. This example also highlights the alternative syntax for a tag with no data indicated by the trailing slash.

XML has the advantage over JSON and YAML when complex data structures come into play. It has a higher overhead and making it more work if the creator is a human rather than a program.


JSON is a simpler encoding method that retains the flexible entry format of XML. Two standards address JSON at this point, RFC 7159 and ECMA-404. RFC 7159 addresses some security and semantic issues whereas ECMA is primarily a syntax definition.

JSON uses name/value pairs. It also has a number of basic data types including numbers, strings, booleans, and null. It also supports arrays and objects (Fig. 5).

{ “people”: [ { “person”: { “firstName”: “Charles”, “lastName”: “Schulz” } }, { “person”: { “firstName”: “Walt”, “middleName”: “Elias”, “lastName”: “Disney” } }, { “person”: { “firstName”: “Gary”, “lastName”: “Larson” } } ] }

5. JSON’s name/value pairs are collected in a structured object bounded by curly brackets. Arrays are indicated by square brackets.

JSON’s syntax matches JavaScript, but typically a parse function is used to convert JSON text to a JavaScript object. This adds a level of protection from malicious code since JSON data is often sent over the Internet on an unsecure channel. It also addresses bad data issues.

JSON is often used with JavaScript Ajax techniques to exchange data. This can provide a more dynamic, interactive interface for a Web page. JSON support is found in most Web browsers.


JSON is simpler than XML. YAML is even simpler (Fig. 6). It foregoes the brackets, except for inline collections, and uses vertical alignment to indicate structure. Quotes are optional, as everything is essentially a string. Leading and trailing whitespace is ignored, so quotes can still be used especially if special characters are part of a key string.

people: - person: {firstName: Charles, lastName: Schulz } - person: firstName: Walt middleName: Elias lastName: Disney characters: [ Mickey, Donald, Goofy ] - person: firstName: Gary lastName: Larson

6. YAML also uses name/value pairs. Curly brackets indicate lists of pairs. Arrays are indicated by dashes, “-”, or square brackets.

In the example, the person: key could not be used on a line by itself because keys within a structure at a particular level must be unique. The dash indicates an array element. Arrays are just structures with numeric keys. YAML syntax options allow the same data to be represented in different ways (Fig. 7).

people: 0: person: {firstName: Charles, lastName: Schulz } 1: person: firstName: Walt middleName: Elias lastName: Disney characters: - Mickey - Donald - Goofy 2: person: firstName: Gary lastName: Larson

7. YAML’s different syntax options allow data to be presented in different ways.

As with Python, it helps to have a text editor that understands the syntax—IDEs like Eclipse that have text editors that understand YAML and do things like auto indentation or column moves.

Functions are available to convert native data structures to and from XML, JSON, and YAML. These are typically used by an application and often a user will never see this data. Still, many platforms utilize this for configuration information that a programmer or user generates.

For example, Drupal, a content management system (CMS), is now based on Symfony, a PHP framework, that uses YAML for its configuration files. There is actually a configuration management system that converts YAML configuration files for system modules and stores them in a database in serialized, PHP data format.

JSON, XML and YAML have their place in many existing environments like Drupal and Symfony. It is a requirement for using those platforms. For new applications, the choice is yours.
