The Latest SBCs to Finish Out Summer 2025 (Part 1)

Sept. 3, 2025
With the seasons about to change, we thought it’s also the right time to highlight the top single-board computers that recently arrived to the market.

Single-board computers (SBCs) are advancing at a breakneck pace to utilize the latest technologies, even packing AI acceleration into ever-shrinking footprints. This roundup takes a look at the first six of the latest SBCs to land on the market. Each integrates a unique blend of compute power, expandability, and design choices aimed at engineers, developers, and makers who need more than just a Raspberry Pi clone.

Radxa Cubie A5E

The Cubie A5E is Radxa’s latest compact Arm-based SBC built around the Allwinner A527 SoC that’s equipped with an octo-core Cortex-A55 and an embedded XuanTie E906 RISC-V core for RTOS applications.

The board features up to 4 GB of LPDDR4 RAM, an Arm Mali-G57 MC1 GPU, and an optional AI accelerator that can deliver up to 2 TOPS. Storage options include a 128-Mb SPI flash for the bootloader, an M.2 M-Key 2230 socket for NVMe SSDs, and a microSD card slot.

Networking options for the Cubie A5E include a pair of Gigabit Ethernet RJ45 ports (Maxio MAE0621A transceivers), PoE-compatible dual-band Wi-Fi 6, and a Bluetooth 5.4 module (BLink BL-M8800DS2). Ports are plentiful with this board, featuring an HDMI 2.0a port, MIPI FPC connector, 4-lane MIPI CSI interface, USB 3.0 port, and USB 2.0 OTG Type-C port. It also has a 40-pin header that’s compatible with Raspberry Pi Hats.

StarFive VisionFive 2 Lite

StarFive’s VisionFive 2 Lite is a low-cost, edge-computing platform and compact media hub that’s driven by a JH7110S SoC. The SoC integrates a quad-core 64-bit RISC-V processor, up to 8 GB of LPDDR4 RAM, and an Imagination BXE-4-32 GPU.

The Raspberry Pi-like board also incorporates a microSD card slot, SPI flash for the bootloader, and NVMe SSD support via an M.2 M-Key 2242 (PCIe Gen2 x1) socket. It can come equipped with eMMC flash; however, it’s only available upon request.

In addition, the VisionFive 2 Lite features an HDMI 2.0 port, 2-lane MIPI DSI connector, and a 2-lane MIPI CSI camera connector. Networking options include a Gigabit Ethernet RJ45 port and optional Wi-Fi 6 and Bluetooth 5.4. There’s also a variety of ports: single USB 3.0 port, 3x USB 2.0 ports, and a 40-pin GPIO header. StarFive is currently offering the VisionFive 2 Lite on Kickstarter.

Orange Pi 5 Pro

The Orange Pi 5 Pro is the company’s answer to the Raspberry Pi 5, which comes with a Rockchip RK3588S SoC outfitted with an octa-core processor with 4x Cortex-A76 cores. The board offers up to 16GB of LPDDR5 RAM, an Arm Mali-G610 MP4 GPU, an eMMC socket, an M.2 2280 M-Key socket for NVMe (PCIe 2.0 x1) or SATA SSD, and a MicroSD card slot for storage.

The Orange Pi 5 Pro is outfitted with an HDMI 2.1 port, HDMI 2.0 port, 4-lane MIPI DSI connector, and a pair of 4-lane MIPI CSI connectors. The board also sports a Gigabit Ethernet RJ45 port with optional PoE support and dual-band Wi-Fi 5 and Bluetooth 5.0 with BLE support. Ports on the board are standard, including a USB 3.0 port, 3x USB 2.0 ports (two behind a USB hub chip), 2x USB 2.0 via header, and 40-pin header.

Banana Pi BPI-F4

The Banana Pi BPI-F4, a compact industrial-grade edge AI development board, is designed around a Sunplus SP7350 SoC. The SoC integrates a quad-core Cortex-A55 CPU, a Cortex-M4 MCU, 4 GB of LPDDR4 SDRAM, 32 GB of eMMC flash, a microSD card slot, and an AI accelerator capable of delivering 4.1 TOPS.

The board also has an HDMI port (1080p max) implemented via MIPI DSI-to-HDMI bridge, MIPI CSI, a Gigabit Ethernet RJ45 port via Realtek RTL8211F PHY, and an M.2 socket for Wi-Fi modules. Additional ports include a USB 3.0 Type-A port (shared with Type-C), a USB 3.0 Type-C port (shared with Type-A), a USB 2.0 Type-A port, and a USB 2.0 Type-C port.

Kiwi Pi 5 Ultra

Rockchip’s Kiwi Pi 5 Ultra is designed for demanding applications, including AI, industrial systems, and ultra-high-definition multimedia. The board is built around a Rockchip RK3588 SoC equipped with 4x Cortex-A76 processors, up to 32 GB of LPDDR4X RAM, a Mali-G610 MC4, and a triple-core NPU capable of delivering 6 TOPS. Storage options include up to 512 GB of eMMC flash and a microSD card slot.

Also in the mix are a single USB Type-C port, 4x USB 2.0 ports, a pair of USB 2.0 ports, 2x RS-232 ports, and a single RS-485 port. Other ports include Wi-Fi 6, BT5.4, and 2x RJ45.

ESWIN EBC77

Canonical and ESWIN recently released the EBC77 RISC-V SBC with Ubuntu support. It’s designed for education, embedded systems, and general-purpose applications.

The board is built around an EIC7700X quad-core, 64-bit RISC-V SoC with 4x SiFive Performance P550 RV64GC RISC-V cores, 64-bit LPDDR5 RAM (unknown how much), and an NPU capable of delivering up to 20 TOPS.

The EBC77’s design looks similar to the Raspberry Pi. It maintains 8 MB of SPI NOR flash and a microSD card slot for storage options, Micro HDMI output, a 4-lane MIPI DSI TX or 4-lane MIPI CSI RX connector, and a 4-lane MIPI CSI connector for video and camera applications.

The board also incorporates a Gigabit Ethernet RJ45 connector, dual-band Wi-Fi 5 (802.11ac), and Bluetooth 5.0 via an Ampak AP6256 module. Additional features include 2x USB 3.2 Gen1 Type-A ports, 2x USB 2.0 Type-A ports, a 4-lane PCIe Gen3 FPC connector, and a 40-pin GPIO header.
