Rohde & Schwarz touts 5-GHz analysis bandwidth at EDI CON
Munich, Germany. Rohde & Schwarz announced it is addressing the fast-growing demands for characterizing wideband components and systems by introducing the new R&S FSW-B5000 option. In combination with the R&S RTO2064 digital oscilloscope as an external digitizer, the R&S FSW85 signal and spectrum analyzer equipped with the new hardware option provides equalized 5-GHz signal analysis bandwidth, which is required for analyzing wideband signals such as automotive radar FMCW chirp signals, IEEE 802.11ay signals, and 5G waveform candidates.
The amplitude and phase response of the R&S FSW85 together with the R&S FSW-B5000
The transient and pulse measurement applications for the R&S FSW allow in-depth, wideband analysis of FMCW chirp signals and hopped and pulsed radar signals required for automotive radar applications. The R&S FSW-B5000 option also makes it possible to capture IEEE 802.11ay wideband signals for postprocessing and to perform measurements on waveform candidates for the future 5G standard.
The R&S FSW-B5000 option for the R&S FSW85 high-end signal and spectrum analyzer is now available from Rohde & Schwarz. It is being demonstrated for the first time to the public through September 13 at EDI CON Boston.
