Coilcraft to present high-voltage coupled inductors at APEC 2018

March 1, 2018
Coilcraft Lpd8035 V Photo

Cary, IL. Coilcraft announced it will present its new LPD8035V Series miniature, high-voltage 1:1 coupled inductors at the Applied Power Electronics Conference (APEC) being held March 4-8 in San Antonio. The LPD8035V provides 1,500-VRMS, one-minute isolation (hipot) between windings from a package that measures just 7.92 x 6.4 x 3.5 mm, providing users with size and cost reductions over conventional bobbin-wound alternatives. It is suitable for Flyback, SEPIC, and isolated buck-converter designs.

Coilcraft Lpd8035 V Photo 300x252
The LPD8035V Series is currently offered in six inductance values ranging from 4.7 to 150 µH. It provides peak current ratings up to 2.7 A, which represents a 40% increase over previous generation products. It also has a tight coupling coefficient (≥ 0.97).

LPD8035V coupled inductors are qualified to AEC-Q200 Grade 3 standards (-40° to +85°C ambient), making them suitable for automotive and other high-temperature applications. They feature RoHS compliant matte tin over silver-platinum-glass frit terminations and are halogen free.

www.coilcraft.com
