6-in-1 Oscilloscope Debugs Virtually Any Embedded Design

Nov. 10, 2014
At Electronica, Tektronix will be showcasing a variety of test and measurement solutions, including the MDO3000, a 6-in-1 oscilloscope

At Electronica, Tektronix will be showcasing a variety of test and measurement solutions, including the MDO3000, a 6-in-1 oscilloscope. The MDO3000 includes a spectrum analyzer, logic analyzer, protocol analyzer, arbitrary function generator, and digital voltmeter to test and debug virtually any embedded design. Also on display will be the TBS1000B-EDU series of oscilloscopes that feature an integrated courseware system designed to help students learn more effectively. With the courseware, instructors can make their lab exercise content viewable on the oscilloscope so students can capture results straight from the instrument.

Recently enhanced with the High Power Interface Panel Model 8020, the Keithley Parametric Curve Trace Configurations on the 2600- / 4200-PCT Series delivers results for high power semiconductor I-V and C-V testing.  The addition of 8030 expands I-V and C-V characterization solutions by high power I-V and high voltage C-V at wafer-level. The Keithley Precision Measurement Power Supply 2280S Series provides a large dynamic range, current measurement resolution of 100 nA, and a graphical user interface (GUI) that enables designers to test power consumption for portable devices.

TEKTRONIX
