In each of these applications, engineers require digitizers with the highest precision and performance possible coupled with a compact footprint for increased channel density. In the case of high-energy physics research, physicists, engineers and technicians often invest weeks to orchestrate “single-shot” events and need confidence that the test results captured by digitizers are valid. The 6 Series Low Profile Digitizer delivers that confidence regardless of the number of input channels, which can number in the 100s for large projects.
“With the 6 Series Low Profile Digitizer, we are bringing a new level of performance and density to research labs and high-end production and manufacturing test applications in military, automotive, 5G and more,” said Brian Ice, General Manager, Core Real-Time Scopes at Tektronix. “The combination of low-noise performance and compact size is unmatched in the industry and allows customers to accomplish more with reliable and repeatable test results.”
The 6 Series Low Profile Digitizer uses the same Tektronix-designed 12-bit Tek049 ASIC on each of its four channels as the 5 and 6 Series Mixed Signal Oscilloscopes. It is available in multiple bandwidth options ranging from 1 GHz to 8 GHz and offers a 25 GS/s sample rate with industry leading low noise performance and a highly effective number of bits. With patented analog-to-digital converter (ADC) and Digital Down Conversion (DDC) signal paths, users can acquire 2 GHz of RF capture bandwidth in Spectrum View while independently controlling the frequency and time domains. To maintain better accuracy over long periods of time, the 6 Series Low Profile Digitizer can run signal path compensation without the need to remove cables or signals.
The 6 Series Low Profile Digitizer is available worldwide. For more information go to: https://www.tek.com/oscilloscope/6-series-low-profile-digitizer.
