16-Bit Micro Handles Mobile Graphics and Multitouch Input

June 23, 2010
$jq().ready( function() \{ setupSidebarImageList(); \} );

16-MHz PIC24FJ256DA

Microchip’s 16-MHz PIC24FJ256DA microcontroller family mixes three accelerated graphics controllers with 24-channel mTouch multitouch inputs. The chip handles resolutions up to 640 by 480, and the controller has a color lookup table. The 16-bit PIC family supports up to 96 kbytes of RAM and 256 kbytes of flash. The multitouch support is implemented using 10-bit analog-to-digital converters (ADCs). The chip also has three comparators, two DMA channels, five timers, nine pulse-width modulation (PWM) timers, four serial ports, three serial peripheral interface (SPI) ports, and three I2C ports. The Full Speed USB 2.0 port can be a host, peripheral, or On-The-Go (OTG) support. The development kit is priced at $399. It includes a QVGA LCD and a development board with USB and capacitive touch pads. Microchip’s ICD-3 and MPLAB integrated development system both support the board.

Microchip
