8-Channel Gate Driver Improves Efficiency of 48-V Mild-Hybrid Vehicles
The L98GD8 gate driver from STMicroelectronics is an integrated solution optimized for driving the gates of NMOS or PMOS FETs in 48-V systems. Its eight fully configurable channels drive MOSFETs in flexible high- and low-side configurations.
Able to operate from a 58-V supply, the L98GD8 provides rich diagnostics and protection for safety and reliability of mild-hybrid systems such as integrated starter-generators, as well as other large 48-V loads like e-compressors, pumps, fans, and valves.
The automotive-qualified driver IC has eight independent, configurable outputs, allowing it to control MOSFETs connected as individual power switches or as high- and low-side switches in up to two H-bridges for DC-motor driving. It features individually programmable gate currents and per-channel diagnostics for short-circuit to battery, open-load, and short-to-ground faults.
Additional diagnostic features include logic built-in self-test (BIST), over/undervoltage monitoring with hardware self-check (HWSC), and a configurable communication check (CC) watchdog timer. The device also includes an ultra-fast overcurrent shutdown with dual-redundant failsafe pins, battery-undervoltage monitoring, an ADC for battery and die temperature monitoring, and H-bridge current limiting.
The L98GD8, housed in a 10- × 10-mm TQFP64 package, is available now. Pricing starts at $3.94 for orders of 1,000 pieces. Click here for information on an evaluation board for the driver.
