MUNICH, GERMANY. Rohde & Schwarz announced that IoT solutions provider Sierra Wireless has selected the compact antenna test range (CATR)-based R&S ATS1800C for mmWave frequencies (FR2) testing. The transportable solution from Rohde & Schwarz features a state-of-the-art golden CATR reflector with rolled edges and a smooth surface to minimize scattering and to provide precise measurement results as required for operation at high frequencies.
The R&S ATS1800C is a turnkey, high-end chamber with a small footprint of only 1.3 m2. Thanks to its movable design, it is highly flexible and transportable, allowing the chamber to be easily moved from one lab to another. The solution provides a large quiet zone of 30 cm, fulfilling 3GPP 5G NR conformance test requirements. With its high shielding efficiency, the R&S ATS1800C is designed to provide a trouble-free environment for uninterrupted measurements of 5G antennas, modules and devices.
A unique characteristic of the R&S ATS1800C is its gold CATR reflector, transforming the incoming spherical wave front to a plane wave. Manufacturing the reflector requires processes that are accurate in the micrometer range. To achieve such high precision, Rohde & Schwarz has developed an innovative manufacturing method, delivering high quality reflectors reproducibly.
The R&S ATS1800C supports the testing of devices weighing up to 8 kg, which makes it well suited for testing a variety of active or passive DUTs, from small chip modules to tablets and laptop or even small cells. Hardware triggering allows measurements during continuous movement of the high-precision 3D positioner, which can reduce measurement time by a factor of 5 to 10.
Bill Seefeldt, senior vice president of engineering at Sierra Wireless, commented, “As a wireless solutions leader, we wanted to find a CATR-based solution to ensure the best measurement quality and accuracy. We were impressed with the OTA solutions Rohde & Schwarz offers, and we selected the R&S ATS1800C. Sierra Wireless is a long-standing customer of Rohde & Schwarz.”
Alexander Pabst, vice president of systems and projects at Rohde & Schwarz, added, “Rohde & Schwarz is committed to providing top-of-the-line T&M solutions to our customers in the mobile-communications industry. We are pleased to provide Sierra Wireless with the unique, gold reflector version of the R&S ATS1800C. We look forward to further cooperation with Sierra Wireless on cutting-edge wireless communications technologies.”
