EV-Pluribus Unum: Protocols and Transition Challenges of the NACS/SAE J3400 EV Charging Interface (Part 2) (Download)

April 19, 2024

Read this article online.

In Part 1, we introduced the SAE J3400 EV charging interface standard and Tesla's NACS connector that it's based on. As we mentioned, the specification includes a series of interlocks and safety protocols to ensure that only one power-delivery path can be active at a given time (Fig. 1). Both the SAE J3400 connector and the latest version of the Tesla charging interface, referred to as NACS (2021 and beyond), support vehicle-charger communications using the dual-mode powerline communication (PLC) protocol defined in the IEC 61851 standard.
