Rohde & Schwarz and Rosenberger verify MultiGBASE-T1 Compliance Test to OPEN Alliance TC9 Specification
Nov. 18, 2020
Rohde & Schwarz and Rosenberger have successfully demonstrated compliance testing for MultiGBASE-T1 supporting 2.5/5/10GBASE-T1 automotive Ethernet speeds, based on the OPEN Alliance TC9 working group t
Rohde & Schwarz, together with connector and cable assembly manufacturer Rosenberger have successfully demonstrated compliance testing for MultiGBASE-T1 supporting 2.5/5/10GBASE-T1 automotive Ethernet speeds, based on the OPEN Alliance TC9 working group test specification. The TC9 group of the OPEN Alliance recently released the first version of a specification for testing components, link segments and the entire Ethernet channel for fully-shielded 1000BASE-T1 and 2.5/5/10GBASE-T1.
The specification defines various RF performance parameters to be tested, for example insertion loss, return loss and cross-talk. This also includes requirements on the measurement fixtures, where Rosenberger offers a complete portfolio for a large variety of connector types – all designed and fully verified according to TC9.
During the successful demonstration, Rosenberger provided a fully-shielded H-MTD® cable assembly and a pair of matching measurement adapters 02K3E6-S00 with Rohde & Schwarz supplying the R&S ZNB8 4-port vector network analyzer. The performance of all individual components as well as the whole link segment was tested against the new TC9 specification and verified as compliant.
