High-Current PMBus Converters with Integrated MOSFETs

Aug. 27, 2014
Texas Instruments (TI) introduced the industry's first 18-V, 20-A and 30-A synchronous DC/DC buck converters with PMBus interface.

Texas Instruments (TI) introduced the industry's first 18-V, 20-A and 30-A synchronous DC/DC buck converters with PMBus interface. The SWIFT TPS544B20 and TPS544C20 converters feature small QFN packages and integrated MOSFETs to drive ASICs in space-constrained and power-dense applications in various markets, including wired and wireless communications, enterprise and cloud computing, and data storage systems. Used in conjunction with TI's award-winning WEBENCH® online design tools, the converters simplify power conversion and speed the power supply design process. For more information, samples and an evaluation module, visit www.ti.com/tps544b20-pr and www.ti.com/tps544c20-pr.

The highly integrated converters feature 0.5 percent reference voltage accuracy and fully differential remote voltage sensing to meet voltage requirements of deep sub-micron processors. Selectable D-CAP or D-CAP2 adaptive on-time control mode is easy to use, provides very fast load transient response and reduces external component count.  Programmability, real-time monitoring of the output voltage, current and external temperature, and fault reporting via PMBus simplifies power supply design, increases reliability and reduces component count and system cost. Watch a video on the benefits of buck regulators with PMBus interface.

Features and Benefits

  a.. Integrated power MOSFETs support 20-A and 30-A continuous output current.

  b.. On-chip PMBus interface and non-volatile memory simplify power supply design, provide voltage, current and temperature monitoring, and enable customization of the power supply.

  c.. Selectable D-CAP or D-CAP2 adaptive on-time control mode eliminates output capacitors and requires no loop compensation, which minimizes the external component count.   d.. Other features include internal soft start, input under-voltage protection and thermal shutdown.

The WEBENCH Designer and Architect component libraries include more than 40,000 components from 120 manufacturers. Price and availability is updated hourly by TI's distribution partners for design optimization and production planning. Offered in eight languages, the user can compare complete system designs and make supply chain decisions in minutes. Start a cost-free design in TI's WEBENCH design environment.

The SWIFT buck converters are available in volume now from TI and its authorized distributors. Packaged in a 40-pin, 5-mm by 7-mm by 1-mm QFN package, the 20-A TPS544B20 is priced at US$3.70 and the 30-A TPS544C20 is priced at US$3.90 in 1,000-unit quantities.
