Three Major Design Pitfalls Plaguing New Analog Signal-Path Designers (Download)

March 6, 2023

Read this article online.

Having been on the receiving end of designer queries from 1985 forward, there are some common oversights and misunderstandings that show up regularly. These essentially fall into three areas:

  1. Not considering the actual operating voltage range on the I/O or internal pins of the device being used.
  2. Misunderstanding the elements that contribute to an output dc offset or drift error.
  3. Accidentally building an oscillator (or even worse, a nominally stable design that slips over into oscillation over production and/or temperature ranges).
